edited by  P. A. Besse,
J. Brugger,
M. Gijs,
R. S. Popovic,
Ph. Renaud


Vol. 4:

Luarent Chiesi
Planar 2D Fluxgate

Magnetometer for

CMOS Electronic


Konstanz 1999. IV, 132 p.; € 64,00.

ISBN 3-89649-478-3



This book deals with the study, development and characterization of a CMOS integrated planar 2D fluxgate magnetometer. The key elements of the sensor are its amorphous ferromagnetic core cleverly combined with a single excitation coil and a pulsed magnetizing field. High sensitivity and high performances have been achieved with this new device for low power consumption. The sensor fabrication uses a CMOS standard process and a CMOS compatible post process. Such an integrated magnetic sensor has wide applications as electronic compass, current sensor or proximity sensor.



Keywords: CMOS integrated planar 2D fluxgate magnetometer, ferromagnetic core, single excitation coil, pulsed magnetizing field, low power consumption, integrated magnetic sensor, electronic compass, current sensor,  proximity sensor
